Network overview
This is a picture of the PC network at home. The hardware is spread between the livingroom and a desk in the attic and a spare room.
It comprises PC and networked hometheatre equipment.
Network schematic showing vlan separation
4 ethernet cables are used to connect the 4 rooms with each other. The 4 switches are connected in a ring topology. Vlan seperation ensures all cables are utilized fully and no loops occur.
See the other tabs on this page for a description of the various parts.
Click here for a nice tutorial for wiring UTP
Networking equipment
| Asus Lyra Trio (3 pack) wireless router/accespoint Wifi mesh system with ethernet backhaul |    |
| Netgear gs110emx 10 port vlan managed switch with 2x 10Gbe ports and 8x 1Gbps |  |
| HPE 1950-24G-2SFP+-2XGT 28 port vlan managed switch with 4x 10Gbe ports HP code : JG960A |  |
| Network all-in-one color laser printer HP cm1312nfi |  |
| Fritz!box 7590 ADSL modem for DSL and Fiber - 100Mbit down / 100 Mbit up Fiber via XS4ALL |  |
| Ziggo Connectbox Compal ch7465lg docsis 3.0 cable modem - 500mbit down / 40mbit up cable internet via Ziggo |  |
| Netgear GS105 5 port gbit switch |  |
| Netgear GS108 8 port gbit switch |  |
| 3com 3c1670800 8 port officeconnect, gigabit switch |  |
| Cisco SLM2008 8 port vlan managed switch |  |
| Cisco SLM2008 8 port vlan managed switch |  |
| Cisco SLM2008 8 port vlan managed switch |  |
| Cisco SLM2008 8 port vlan managed switch |  |
This is a selection of the previous hardware I have used over the years :
Previous motherboards/CPU combinations :
 <=== Asus A7V133 |
 <=== AMD Athlon ThunderbirdC 1000 & 1400 |
 <===Asus P5A |
 <=== K6-2 300 |
 <=== Asus P55T2P4 |
 <== K6-200 |
To tweak the T2P4 motherboard a lot of info can be found on Kalle's page that I copied from Kalle
With thanks to tomshardware for several of the pictures shown here.
